Insulated Concrete Forms for Amazing Buildings

Insulated Concrete Forms (ICFs) create the most comfortable, peaceful & healthy living environments with quick construction of truly durable, resilient and sustainable buildings.

Insulated Concrete Forms for Floors and Roofs
Quad-Lock uses unique technology to create an energy efficient and quality insulating concrete floor and roof system. Ideal for use in commercial and residential construction, Quad-Lock combines the strength, security, and reliability of reinforced concrete with the energy efficiency, fast construction, and comfort of insulating concrete forms.
Each of the expanded polystyrene (EPS) panels are supported and reinforced with two integral steel beams molded into the product from end to end. The result is a self-supporting joist and deck forming system that provides the maximum strength of a reinforced concrete deck with a minimum of materials and labor. Contact us today to find out about using Quad-Lock for your next project.
Benefits for Owners
  • Quiet, Healthy, Safe & Comfortable
  • More consistent indoor temperatures
  • Perfect for in-floor radiant heating
  • High STC ratings dampen sound transmission
  • Minimized air infiltration – fewer allergens, improved indoor air quality
  • Inert materials: doesn’t support the growth of mold or mildew
  • Rated Fire Resistance (using 2 hour 40 minute test results or ACI 216.1)
  • Not a food source for insects
  • Superior protection against disasters
  • Durable & Sustainable
  • High R-Values* (low U-Values) & low air infiltration
  • Reduced HVAC requirements, heating and cooling costs
  • Thermal mass properties, ideal for passive solar designs
  • Lower life-cycle costs & emissions
  • Long-term building durability with life-cycle measured in centuries
  • Fast & Flexible
  • Lightweight, easy to handle – no forms to be stripped
  • Delivered to site ready to install – pre-cut at factory to exact specifications
  • Self-reinforced forms – temporary shoring only every 5-6′
  • Available in thicknesses of 7″ to 12½”, up to 34′ [10.3m] free spans (and more with additional EPS caps or post-tensioning)
  • Slab thickness from 1¾” to 6″ [45mm to 152mm]
  • Easily integrates with Quad-Lock ICF system
  • Lightweight
  • Lighter structure; eliminates upto 50% of conventional shoring
  • Reduces floor mass dead load by up to 50%
  • Reduces structural requirements for foundations and walls
  • Reduced Costs
  • Minimal or no site waste
  • Uses less concrete & steel compared to traditional concrete slab
